Make Your Own PCBs with EAGLE: From Schematic Designs to Finished Boards by Simon Monk

Fully updated coverage of PCB design and construction with EAGLE This thoroughly revised, easy-to-follow guide shows, step-by-step, how to create your own professional-quality PCBs using the latest versions of EAGLE. Make Your Own PCBs with EAGLE: From Schematic Designs to Finished Boards, Second Edition, guides you through the process of developing a schematic, transforming it into a PCB layout, and submitting Gerber files to a manufacturing service to fabricate your finished board. Four brand-new chapters contain advanced techniques, tips, and features. Downloadable DIY projects include a sound level meter, Arduino shield, Raspberry Pi expansion board, and more! • Install and configure EAGLE—including EAGLE v7.7.0 • Explore EAGLE’s screens and create schematic and board files • Select the right components and launch your own projects • Create scripts and User Language Programs that automate repetitive tasks • Build your own libraries and parts and modify existing components • Generate Gerber design files to submit for fabrication • Solder through-hole PCBs and SMD boards • Learn how to streamline your design thinking and workflow • Design non-rectangular and custom-shaped boards • Learn advanced techniques and take your boards to the next level
