The Creo Parametric 3.0: Sheet Metal Design learning guide enables you to use your introductory modeling skills to create sheet metal models, including wall, bends, notches, and form features. On completion of this course, you will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts.

Topics Covered

• The sheet metal environment
• Primary and secondary walls
• Bend relief
• Corner relief
• Regular unbends, back bends, and cuts
• Notches and punches
• Bend features
• Unbending complex geometry
• Sheet metal forms
• Documenting a sheet metal part
• Converting solid parts
• Sheet metal setup
• Investigating a sheet metal part

Prerequisites
Creo Parametric: Introduction to Solid Modeling or equivalent Creo Parametric 3.0 experience. Please note that this learning guide uses commercial practice files which may not be compatible with the Student Edition of Creo Parametric

ASCENT creates and distributes a comprehensive range of courseware, knowledge products, and courseware for Autodesk, Dassault Systèmes, and PTC's industry-leading engineering software solutions. Courseware developers, engineers, instructional designers, architects, and technical writers make up ASCENT's team, which collaborates to produce training solutions that work for our clients. Our curriculum team specializes in developing blended education programs that combine the best of expert-led and technology-based training to generate the most effective course content and ensure that customers get the most out of their engineering software. We also endeavor to fulfill the needs of our clients by providing various levels of customisation for classroom-training curriculum.
